Greenstar i System compact (27kW and 30kW) Professional

Greenstar i System compact (27kW and 30kW) overview

Our Greenstar i System is part of the latest generation of smaller and lighter boilers with outputs of 27kW and 30kW.

This boiler, which can be fitted in a standard kitchen cupboard comes with a steel wall-mounting jig that not only allows pipes to go behind the boiler but also the ability to pre-pipe all of the pipework before the boiler is placed on the wall.

The appliance can be used with our range of high efficiency Greenstore cylinders.

Download our easy guide, which covers everything you need to know about the Greenstar i System (27kW and 30kW)

Standard Guarantee

7 Year

With any Greenstar System Filter

8 Year

With any Greenstar System Filter + £40 (Non-WAI loyalty members only)*

10 year

*Available to loyalty scheme members only. Non-WAI’s can achieve this extended guarantee length with an additional payment of £40. Terms and conditions apply.

Features & Benefits

Wall mounting jig providing pre-plumbing and rear piping as standard	Low lift weight	Fits in a standard kitchen cupboard
Central heating flow and hot water temperatures can be adjusted using simple up/down buttons	Plug & play optional Worcester controls available*	Commissioning information for easier completion of the Benchmark checklist
Clear operational information and diagnostic display	High efficiency and greater reliability with our innovative WB7 heat exchanger	Colour-coded wiring connectors for error free connection and removal
Compatible with CondenseSure accessory - eliminates risk of condensate pipe freezing †	Scan and register the boiler using our free MyWorcester App

Technical details

Greenstar 27i System LPG

Part number: 7 733 600 061
ErP Efficiency Rating: A
ErP Data Sheet: ErP Data Sheet
Fuel Type: Gas (LPG)
Control Options
EasyControl Compatible ¹
Solar Compatible
Central heating output (kW): 27
Dimensions (mm) height x width x depth: 690 x 390 x 280
Clearances (mm) above, sides, below and front: 30, 5, 200, 600 (fixed surface) & 20 (cupboard door)
Maximum horizontal flue (mm): 6000
Maximum vertical flue (mm): 6000
Ingress protection rating: X4D
Minimum inlet pressure (bar): N/A
Lift weight (kg): N/A

Greenstar 27i System

Part number: 7 733 600 060
ErP Efficiency Rating: A
ErP Data Sheet: ErP Data Sheet
Fuel Type: Gas (NG)
Control Options
EasyControl Compatible ¹
Solar Compatible
Central heating output (kW): 27
Dimensions (mm) height x width x depth: 690 x 390 x 280
Clearances (mm) above, sides, below and front: 30, 5, 200, 600 (fixed surface) & 20 (cupboard door)
Maximum horizontal flue (mm): 6000
Maximum vertical flue (mm): 6000
Ingress protection rating: X4D
Minimum inlet pressure (bar): N/A
Lift weight (kg): 27.3

Greenstar 30i System LPG

Part number: 7 733 600 063
ErP Efficiency Rating: A
ErP Data Sheet: ErP Data Sheet
Fuel Type: Gas (LPG)
Control Options
EasyControl Compatible ¹
Solar Compatible
Central heating output (kW): 30
Dimensions (mm) height x width x depth: 690 x 390 x 280
Clearances (mm) above, sides, below and front: 30, 5, 200, 600 (fixed surface) & 20 (cupboard door)
Maximum horizontal flue (mm): 6000
Maximum vertical flue (mm): 6000
Ingress protection rating: X4D
Minimum inlet pressure (bar): N/A
Lift weight (kg): N/A

Greenstar 30i System

Part number: 7 733 600 062
ErP Efficiency Rating: A
ErP Data Sheet: ErP Data Sheet
Fuel Type: Gas (NG)
Control Options
EasyControl Compatible ¹
Solar Compatible
Central heating output (kW): 30
Dimensions (mm) height x width x depth: 690 x 390 x 280
Clearances (mm) above, sides, below and front: 30, 5, 200, 600 (fixed surface) & 20 (cupboard door)
Maximum horizontal flue (mm): 6000
Maximum vertical flue (mm): 6000
Ingress protection rating: X4D
Minimum inlet pressure (bar): N/A
Lift weight (kg): 27.3

*With installation of optional built-in diverter valve

† The Condensesure Siphon has been proven to be effective at preventing frozen condensate at -15°C for a sustained period of 48 hours. 32mm pipework must be used and should not exceed 3 metre

Related Accessories

Boiler Accessories	Part number
CondenseSure	7 716 192 746
Vertical Pre-piping Assembly Kits	7 716 192 713
ISM1 Intelligent Solar Module	7 716 192 068
Below boiler pipe cover	7 716 192 608
Optional 27kW diverter valve kit	7 716 192 758
Optional 30kW diverter valve kit	7 716 192 759
Greenstar Comfort wall mounting plate	7 733 600 039
EasyControl Adapter	7 736 701 560	Installation Manual

Flashing Kits	Part number
Flat roof flashing kit (100mm & 125mm dia.)	7 716 191 090
Pitched roof flashing kit (100mm & 125mm dia)	7 716 191 091

Flue	Part number
Standard telescopic horizontal flue kit (100mm dia)	7 716 191 0822	WallHung	Gas
1000mm extension kit (100mm dia.)	7 716 191 083
90º bend (100mm dia.)	7 716 191 084
Short flue extension, 220mm (100mm dia)	7 716 191 133
2m flue extension (100mm dia.)	7 716 191 172
High level horizontal flue adaptor (100mm dia)	7 719 002 432
High level horizontal flue adaptor (125mm dia)	7 719 002 433
Vertical BF kit (100mm)	7 719 002 4302
Vertical BF kit (125mm)	7 719 002 4312
60/100mm (x2) 45º bends	7 716 191 085
Horizontal flue kit (125mm dia.)	7 719 003 7022
1000mm extension (125mm dia.)	7 719 003 666
45 degree bend (80/125mm dia.)	7 719 003 665
90º bend (125mm dia.)	7 719 003 664
Long telescopic flue kit (100mm dia.) - wall hung boilers	7 716 191 171	WallHung	Gas
Support bracket kit (100mm dia.)	7 716 191 177
Support bracket (125mm dia.)	7 716 191 179
Support bracket 6 pack (100mm dia.)	7 716 191 178
Standard Telescopic Flue & Terminal (White)	7 716 191 082	WallHung	Gas	Installation Manual

Plume	Part number
45º bend (x2)	7 716 191 089
90º bend	7 716 191 088
Plume management terminal guard round (60mm dia.)	7 716 191 176
Plume management kit (60mm dia)	7 716 191 086
